| Optional Accessories for Converters |
|
||||||||||
| Enclosure-S | $8.00 | Custom Enclosure (Plastic) | |||||||||
| Enclosure-M | $10.00 | Custom Enclosure (Plastic) | |||||||||
| Enclosure-D | $12.00 | Din Enclosure w/ Metal Clip | |||||||||
| DB9F-7 | $7.50 | 7ft Cable & DB9F Adapter | |||||||||
| DB25F-7 | $7.50 | 7ft Cable & DB25F Adapter | |||||||||
| DB9M-7 | $7.50 | 7ft Cable & DB9M Adapter | CONVERTERS | ||||||||
| DB25M-7 | $7.50 | 7ft Cable & DB25M Adapter | |||||||||
| 12VDC-SPS | $8.50 | 12VDC @ 400mA Wall SPS | |||||||||
| 12VDC@1A | $9.75 | 12VDC @ 1.0A Wall SPS | Updated April 9, 2020 - Many other products available. | ||||||||
| NEED HELP SELECTING A CONVERTER? GIVE RON A CALL @ 513-874-4796 or 513-638-0228 Cell. RS232 = 3-WIRE (115.2K@10ft.), RS485 = 2-WIRE(100kbps@4000ft.), RS422 = 4-WIRE(100kbps@4000ft.) Our entire product line will operate at Data Rates up to 115.2Kbps (and above), from -40C to 85C and relative humidity from 10-90% (non-condensing) USB 0-70C | |||||||||||
| Model Links | Board Price | Conversion | Speed (bps) | LEDs | Galvanic Isolation | Voltage Range | Duplex | Auto-TX Enable | Trans. Supp. | SIZE CODE | Comments |
| RS232 to RS485 (AUTO TX ENABLE) CONVERTERS (HALF-DUPLEX) | |||||||||||
| RSFC24W | $43.00 | RS232 to RS485 (Rev. B) | DC-115.2k | None | No | 8-15VDC Lin | Half | Yes | No | S1 | RS485 Wago TS |
| RSFC24R | $43.00 | RS232 to RS485 (Rev. B) | DC-115.2k | None | No | 8-15VDC Lin | Half | Yes | No | S1 | RS485 RJ12 |
| ASC24W | $45.00 | RS232 to RS485 (Rev. B) | DC-115.2k | 3 | No | 8-15VDC Lin | Half | Yes | No | S1 | RS485 Wago TS |
| ASC24R | $45.00 | RS232 to RS485 (Rev. B) | DC-115.2k | 3 | No | 8-15VDC Lin | Half | Yes | No | S1 | RS485 RJ12 |
| ASC24T | $49.00 | RS232 to RS485 (Rev. C) | DC-115.2k | 3 | No | 8-15VDC Lin | Half | Yes | 22-ohm | S1 | RS485 3-PIN TS |
| ASC24TS | $49.00 | RS232 to RS485 (Rev. B) | DC-115.2k | 3 | No | 8-15VDC Lin | Half | Yes | 22-ohm | S1 | RS232/485 6-PIN TS |
| MID-RANGE PRICED UNITS SEE RS232 to RS485/422 CONVERTERS (NEXT SECTION) | |||||||||||
| RSFC2 | $95.00 | RS232 to RS485 (Rev B1) | DC-115.2k | 2 | No | 9-35VDC Sw | Half | Yes | Yes | M1 | uP Bit or Character Timing |
| RSFC2-DIN | $119.00 | RS232 to RS485 (Rev B) | DC-115.2k | 3 | No | 9-35VDC Sw | Half | Yes | Yes | M1 | uP Bit or Character Timing |
| IRSFC24 | $99.00 | RS232 to RS485 (Rev C) | DC-115.2k | 5 | 3.0KV | 9-35VDC Sw | Half | Yes | Yes | M2 | RJ12 and Wago TS |
| IRSFC24FB -C (CONV) | $109.00 | RS232 to RS485 (Rev C) | DC-115.2k | 3 | 3.0KV | 9-35VDC Sw | Half | Yes | Yes | M2 | RS232/RS485 3-PIN TS Flexible Bias & Termination |
| IHV24AT | $119.00 | RS232 to RS485 (Rev A2) | DC-115.2k | 6 | 3.0KV | 9-35VDC Sw | Half | Yes | Yes | M2 | Isolated with "Robust" Transient Protection |
| QASC24 | $159.00 | QUAD RS232 to RS485 (A) | DC-115.2k | 9 | No | 9-35VDC Sw | Half | Yes | 22-ohm | M8 | QUAD ASC24 - ONE BOARD |
| IRSFC24H | $259.00 | RS232 to RS485 (Rev B4) | DC-115.2k | 4 | 3.0KV | 9-35VDC Sw | Half | Yes | Yes | M2 | 10,000FT+ @ 38.4kBPS USING TWISTED 20AWG |
| NOTE: | MOST OF OUR RS232 CONVERTERS CAN BE CONFIGURED FOR TTL/CMOS OPERATION BY REMOVING THE RS232 IC AND EITHER CHANGING JUMPERS or BY SOLDERING VERY SHORT JUMPERS ON THE REAR SIDE OF THE PCB. PLEASE CALL RON @ 513-874-4796 or 513-638-0228 CELL for ADDITIONAL INFORMATION | ||||||||||
| Model Links | Board Price | Conversion | Speed (bps) | LEDs | Galvanic Isolation | Voltage Range | Duplex | Auto-TX Enable | Trans. Supp. | SIZE CODE | Comments |
| RS232 to RS485/RS422 CONVERTERS (HALF-DUPLEX or FULL-DUPLEX) | |||||||||||
| SSAC44T | $49.00 | RS232 to RS485/RS422 (A) | DC-115.2k | None | No | 8-15VDC Lin | H/F | Yes | No | S1 | RS485/RS422 5-PIN TS |
| RSCOM2A | $79.00 | RS232 to RS485/RS422 (A) | DC-115.2k | 5 | No | 9-35VDC Sw | H/F | Yes | Yes | M1 | RS485/RS422 6-PIN TS |
| RSCOM3A | $79.00 | RS232 to RS485/RS422 (A) | DC-115.2k | 6 | No | 9-35VDC Sw | H/F | Yes | Yes | M2 | Flexible RSCOM2A Replacement |
| IRS422HV | $99.00 | RS232 to RS485/RS422(B1) | DC-115.2k | 6 | 3.0KV | 9-35VDC Sw | H/F | Yes | No | Yes | RS232/PWR 5-PIN TS RS485/RS422 6-PIN TS |
| IRSCOM2A | $115.00 | RS232 to RS485/RS422(B1) | DC-115.2k | 5 | 3.0KV | 9-35VDC Sw | H/F | Yes | Yes | No | RS232 RJ11/12 RS485/RS422 6-PIN TS |
| RS232 to RS422 CONVERTERS (FULL-DUPLEX) | |||||||||||
| RS422S | $39.00 | RS232 to RS422 (REV B) | DC-115.2k | None | No | 8-12VDC Lin | Full | N/A | No | S1 | RJ11/12 to RJ11/12 |
| SSAC44L | $49.00 | RS232 to RS422 (REV A) | DC-115.2k | 3 | No | 8-15VDC Lin | Full | No | No | S1 | RS422 5-PIN TS |
| RSCOM2 | $89.00 | RS232 to RS422 (B1) | DC-115.2k | 6 | No | 9-35VDC Sw | Full | No | Yes | M1 | RS422 6-PIN WAGO TS |
| RSCOM2D | $89.00 | RS232 to RS422 (B) | DC-115.2k | 3 | No | 9-35VDC Sw | Full | No | Yes | M4 | DB9M to RS422 7-PIN TS |
| IRS422 | $99.00 | RS232 to RS422 (B) | DC-115.2k | 3 | 3.0KV | 9-35VDC Sw | Full | No | No | M1 | RS232/PWR 5-PIN TS RS422 6-PIN TS |
| EC232CAT | $109.00 | RS232 CAT-5 FULL-DUPLEX "EXTENSION CORD KIT" with CABLE POWER & DATA (A) | DC-115.2k | None | No | 12VDC Sw (ONE END ONLY) | Full | N/A | No | (2X) S1 | 2 BOARDS/ENCLOSURES , 3FT CAT5 TEST CABLE, 12VDC-SPS PWR SUPPLY |
| RS422 to RS485 "INLINE" CONVERTERS for RS485 "BACKBONE" | |||||||||||
| RSFC44T | $49.00 | RS422 to RS485 (REV B) | DC-115.2k | None | No | 8-12VDC Lin | Half | Yes | No | S1 | RS485 "Backbone" |
| DARC44-C | $99.00 | RS422 to RS485 Rev A | DC-230.4k | 13 | No | 9-35VDC Sw | Half | Yes | Yes | L3 | "Robust" Transient Protection |
| DIACR44 | $189.00 | DUAL ISO RS422 to RS485 | DC-115.2k | 6 | DUAL | 9-35VDC | Half | Yes | Yes | L2 | RS485 or 422 "Backbone" |
| USB to RS485 or RS485/RS422 CONVERTERS | |||||||||||
| USBA4 | $99.00 | USB to RS485 (REV B) | 300-230.4k | 3 | No | USB 5VDC | Half | Yes | Yes | S1 | USB to RS485 3-PIN TS |
| USB44T | $109.00 | USB to RS458/RS422(A) | 300-921.6k | 3 | No | USB 5VDC | Half | Yes | Yes | S1 | RS485/RS422 5-PIN TS |
| IUSB24AT | $149.00 | USB to RS485 (REV A1) | 300-921.6k | 6 | 3.0KV | USB 5VDC | H/F | Yes | Yes | M2 | USB to ISO RS485 3-PIN TS |
| IUSB44T | $159.00 | USB to RS458/RS422(B) | 300-921.6k | 6 | 3.0KV | USB 5VDC | H/F | Yes | Yes | M2 | RS485/RS422 6-PIN TS |
| Model Links | Board Price | Conversion | Speed (bps) | LEDs | Galvanic Isolation | Voltage Range | Duplex | Auto-TX Enable | Trans. Supp. | SIZE CODE | Comments |
| OTHER SPECIAL CONVERTERS | |||||||||||
| ISO232 | $89.00 | RS232 to RS232 | DC-115.2k | 3 | 3.0KV | 9-35VDC Sw | Full | No | No | M1 | RS232 ISOLATOR (3-WIRE) |
| ISO232HV | $109.00 | RS232 to RS232 | DC-115.2k | 3 | 3.0KV | 9-35VDC Sw | Full | No | No | M1 | RS232 ISOLATOR(RTS/CTS) |
| CAS24 | $109.00 | RS232 to RS485/RS422 CODE ACTIVATED SWITCH | DC-115.2k | 4 | No | 9-35VDC Sw | H/F | Yes | Yes | M2 | CODE ACTIVATED RS232 ADDRESSABLE SWITCH |
| XPCOM232 | $149.00 | 10-100-BASE-T to RS232 | 300-115.2k | 4 | No | 9-35VDC Sw | H/F | Yes | No | M1 | RS232 ONLY VERSION |
| XPCOM1 | $169.00 | 10-100-BASE-T to RSXXX | 300-921.6k | 4 | No | 9-35VDC Sw | H/F | Yes | Yes | M1 | XXX=RS232/RS485/RS422 |
| XPF1 | $279.00 | Ethernet to Duplex Fiber | DC-921.6k | 6 | Fiber/ 3.0KV |
9-35VDC Sw | Full | N/A | Yes | M1 | Duplex MM Fiber |
| IHVDSXR (CALL US) | $585.00 | RS232/485/USB to HVDS (High Voltage Diff. Signal) | 1200 up to 921.6k | 7 | Yes | 9-35VDC Sw | Half | Yes | Yes | L1 | Up to 30,000FT+ @ 38.4kBPS using 20AWG |
| SMFCOMX PLATFORM (CALL US) | $389.00 to $950.00 | SM(SC,LC) & MM(ST) Fiber with "Copper Tap Point" & "Communications Glue" for Small & Large Networks | DC-1.0M | 11 | 2.0KV | 9-35VDC Sw | H/F | Yes | Yes | L3 | "X" "Y" "Z" MODULES FOR RS232, RS485, USB,SMF, MMF (20+ CONFIGS) with Very Flexible Operation |
| Model Links | Board Price | Conversion | Speed (bps) | LEDs | Galvanic Isolation | Voltage Range | Duplex | Auto-TX Enable | Trans. Supp. | SIZE CODE | Comments |
| OLDER PRODUCTS - LIMITED QTY or NEWER REPLACEMENTS AVAILABLE | |||||||||||
| IRSFC24T | $219.00 | SMART RS232 to RS485 | DC-115.2k | 5 | 1.5KV | 9-35VDC Sw | Half | Yes | Yes | M2 | REPLACED by IHV24AT |
| IRSFC24XT | $219.00 | SMART RS232 to RS485 | DC-115.2k | 5 | 1.5KV | 9-35VDC Sw | Half | Yes | Dual | M2 | REPLACED by IHV24AT |
| PCI24 (PCI) | $239.00 | ISO RS232 to RS485 | DC-115.2k | 3 | 1.5KV | 5VDC | Half | Yes | Dual | M5 | PCI POWERED CONV |
| BOARD/ENCLOSURE SIZE CODES & DIMENSIONS | |||||||||||
| SIZE CODE | PCB BOARD DIMENSIONS | UNIT APPROX. HEIGHT | BOX SIZE | APPROXIMATE BOX DIMENSIONS | Comments | ||||||
| S1 | 2.50" X 2.00" | 0.9" | SMALL | ||||||||
| M1 | 3.50" X 2.75" | 1.25" | MEDIUM | ||||||||
| M2 | 3.50" X 3.00" | 1.25" | MEDIUM | ||||||||
| M3 | 3.65" X 2.70" | 1.25" | MEDIUM | ||||||||
| M4 | 3.95" X 2.90" | 1.25" | MEDIUM | ||||||||
| M5 | 4.75" X 3.80" | 1.25" | MEDIUM | ||||||||
| M6 | 1.25" | MEDIUM | |||||||||
| M7 | 1.25" | MEDIUM | |||||||||
| M8 | 4.10" X 3.85" | 1.25" | MEDIUM | ||||||||
| L1 | 4.50" X 3.75" | 1.50" | LARGE | ||||||||
| L2 | 4.50" X 3.50" | 1.50" | LARGE | ||||||||
| L3 | 4.75" X 3.50" | 1.50" | LARGE | ||||||||
| L4 | 1.50" | LARGE | |||||||||
| L5 | 1.50" | LARGE | |||||||||
| NOTE: PCB BOARD DIMENSIONS DOES NOT INCLUDE ANY OVERHANG FOR CONNECTORS, LEDs, TERMINALS, ETC. | |||||||||||
| NOTE: | MOST OF OUR RS232 CONVERTERS CAN BE CONFIGURED FOR TTL/CMOS OPERATION BY REMOVING THE RS232 IC AND EITHER CHANGING JUMPERS or BY SOLDERING VERY SHORT JUMPERS ON THE REAR SIDE OF THE PCB. PLEASE CALL RON @ 513-874-4796 or 513-638-0228 CELL for ADDITIONAL INFORMATION | ||||||||||
